Stainless Steel Tube Clamps for Automotive Exhaust & Silencers-Genleelai

Stainless Steel Tube Clamps for Automotive Exhaust & Silencers

Stainless Steel Tube Clamps for Automotive Exhaust & Silencers

share to:

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest

Material Options

  • Premium Stainless Steel (201/304): High-grade materials for exceptional durability and performance.
  • Customization: Tailored variants available upon request to meet specific requirements.

Compatibility

  • Designed to fit a wide range of car brands.
  • Includes universal applications for versatile use across various vehicles.

Material Specifications

  • Constructed from top-quality Stainless Steel 201 or 304 for superior strength, reliability, and corrosion resistance.

HS Code

  • 8708920000

Temperature Range

  • Operates efficiently within a broad temperature range of -20°C to 650°C, ensuring optimal performance in diverse conditions.

Working Pressure

  • Engineered to withstand pressures ranging from 0 to 5 MPa, delivering dependable performance under demanding conditions.

Product Details

Genleelai Autoparts specializes in premium 1.5-inch flexible exhaust pipes and bellows, essential for a variety of industries, including automotive and transportation OEMs, the aftermarket, off-road vehicles, power generation, and marine vessels.

Our flexible exhaust couplings are expertly engineered to perform in high-frequency, low-amplitude vibration environments—conditions typical in engine exhaust systems.

Key Features of Genleelai Autoparts’ Flexible Exhaust Couplings:

  • Stainless Steel Multi-Ply Bellows: Available with or without external braiding to meet diverse application needs.
  • Braided Construction: Offers excellent flexibility and resilience against vibration-induced stress while protecting the bellows from external damage for improved durability.
  • Exceptional Corrosion Resistance: Made from high-quality stainless steel for superior reliability and an extended service life, even in harsh environments.

Choose Genleelai Autoparts for reliable, high-performance exhaust solutions that meet the industry’s most stringent standards.



Genleelai Autoparts offers flexible exhaust pipes with a range of internal liner options, including Inner Braid, Interlock, and Directional Solid Liners, each engineered for high-performance applications.

Benefits of Internal Liners:

  • Protection Against High-Velocity Gases: Shields the bellows from the abrasive effects of fast-moving exhaust gases, ensuring enhanced durability.
  • Noise Reduction: Minimizes turbulence-induced noise for quieter operation and improved acoustic performance.
  • Resonance Prevention: Reduces the risk of resonance, helping to prevent premature bellows failure.

These advanced internal liner designs provide exceptional performance, reliability, and durability, ensuring optimal functionality in even the most demanding environments.



exhaust flexible pipe3 inch flex exhaust pipe

Construction and Structure

Components:

  • Bellows + Double Braid + Nipple + Cap
  • Bellows with Outer Braid / Bellows with Inner Braid
  • Bellows with Interlock / Bellows with Nipples
  • Customization: Tailored structures available to meet specific requirements.

Functions of Components:

  • Bellows: Provide flexibility and absorb shocks, ensuring smooth operation and preventing system stress.
  • Outer Braid: Enhances pressure resistance and protects the bellows from external damage.
  • Inner Braid or Interlock: Direct exhaust flow, protect the bellows, and reduce engine noise for quieter operation.
  • Caps: Securely attach the outer braid to the bellows, ensuring stability and longevity.

Size and Specifications:

  • Inner Diameter (ID): Ranges from 1″ to 6″.
  • Overall Length: Options available from 4″ to 17″.

Standard Inner Diameter (ID) Options:

  • Imperial Sizes: 1-3/4″ (45mm), 2″ (51mm), 2-1/4″ (57.2mm), 2-1/2″ (63.5mm), 3″ (76.2mm), 3-1/2″ (89mm), 4″ (102mm).
  • Metric Sizes: 43mm, 50mm, 52mm, 54.5mm, 60mm, 61mm, 65mm, 70mm.

Standard Overall Length Options:

  • Imperial Sizes: 4″ (102mm), 6″ (152mm), 8″ (203mm), 9″ (230mm), 10″ (254mm), 11″ (280mm), 12″ (305mm).
  • Metric Sizes: 120mm, 165mm, 180mm, 200mm, 240mm, 250mm.

Customization: Tailored sizes, structures, designs, drawings, and logos are available to suit a variety of application needs.


Functions and Features

Corrugated Tube Construction:

  • Manufactured using a double-layer hydraulic pressure process, with water as the forming medium.
  • Provides superior sealing performance and flexibility, ensuring optimal exhaust system functionality.

Flexible Connection:

  • Installed between the engine exhaust manifold and the muffler purifier.
  • Enhances shock absorption and noise reduction, improving the overall performance of the exhaust system.

Applications:

  • Ideal for light-duty vehicles, mini cars, coaches, trucks, and motorcycles.

Performance Benefits:

  • Reduces noise and air pollution, contributing to a cleaner and quieter operation.
  • Simplifies installation and extends the lifespan of the exhaust system.

With customizable options, advanced construction, and high-performance features, Genleelai Autoparts’ flexible exhaust components offer the perfect solution for a wide range of automotive applications.
